🛠 How to Use the Simulator

1. Choose Your Cell Type – Supports 18650, 20700, 21700 cells:
   • 18650: 3.7V, 3Ah
   • 20700: 3.7V, 4Ah
   • 21700: 3.7V, 5Ah
2. Set Series and Parallel Counts:
   • Series (S) – cells connected end-to-end, increases voltage.
   • Parallel (P) – cells connected side-by-side, increases capacity (Ah).
3. View Calculated Results – Displays voltage (V), capacity (Ah), and total energy (Wh = V × Ah) instantly.
4. Visual Representation – Grid shows series/parallel layout. Hover cells to see individual voltage and capacity.

💡 Why Use This Tool

• Quick Planning: Calculate pack specifications instantly without manual math.
• Safe Configurations: Warnings for unsafe series, parallel, or total cell counts.
• Visual Learning: Understand complex battery layouts at a glance.
• Energy Estimation: See how different configurations affect total energy storage (Wh).

Whether you’re designing an e-bike battery, electronics project, or learning about battery packs,
this simulator simplifies planning and prevents costly mistakes.
